Mini Table Saw 300W
Transform Your Child's Screen Time into Set-Building Fun🏰
🧠 Comprehensive Learning Through Play
💡 Stimulate Imagination and Creativity
⚙️ Develop Fine Motor Skills
💚 Safe and Durable Material
Free characters included for the next 36 orders ONLY!
"These blocks are absolutely amazing! Our son is extremely into the game and they work perfect for pretend play, when he just wants to build something, and even for learning. We can use these blocks to set a scene of a story or even for counting, addition, and subtraction."
Application
This mini table saw can be used for cutting, grinding, polishing, carving, and punching PCBs, small wooden sticks, acrylic, copper tubes, thin wooden boards, aluminum alloys, etc.
Use of Four Saw Blades
1.Diamond Saw Blade: It is used to cut honey wax, agate, small jade, pebble, crystal stone, etc.
2.High Speed Hacksaw Blade: It is used to cut plastic, chopsticks, PVC and so on.
3.Grinding Wheel Saw Blade: It is used to cut small steel pipes, small steel plates, stainless steel, small aluminum plates, etc.
4.Multi-function Saw Blade: It is used to cut thick materials such as wood boards, acrylic boards, ABS boards and bakelite boards.
Instructions
Bakelite Milling Operation Instructions
1.Milling slot: Install the cushion and milling cutter, adjust the milling cutter to the right position, and you can start working.
2.Punching: Install the bakelite wash cushion and milling cutter, and press the wood block down against the cushion, and the aperture can be adjusted according to the size of the milling cutter.
3.Milling edge: Install the bakelite milling cushion and milling cutter, align them with the scale, and you can start milling the edge.
Saw Blade Installation Instructions
1.Remove the 4 screws from the table first, loosen the saw blade clamp with a wrench, and take off the outer saw blade clamp.
2.After installing the saw blade, tighten it to be ready for use. (Counterclockwise rotation is loosening the saw blade.)
Drill Chuck Installation Instructions
1.Fix the connecting rod and joint first
Package Included
1 * Mini Table Saw
1 * Instruction Manual
1 * Diamond Saw Blade
1 * High-speed Hacksaw Blade
1 * Grinding Wheel Saw Blade
1 * Multi-function Saw Blade
All Accessories for Installation
Specification
Material: Iron, Aluminum Alloy
Power: 300W
Color: Gold
Working Voltage: 12V-24V
Push Ruler Angle: 0-90°
Cutting Thickness: 0-29mm/0-1.14in
Collet Range: 1.5-10mm/0.06-0.4in
Motor Speed: 9000rpm
Saw Blade Aperture: 16/20mm/ 0.63/0.79in
Package Size: 30*27*21cm/ 11.81*10.63*8.27 in
Product Size: 24*20*13cm/ 9.45*7.87*5.12 in
Net Weight: 5kg/11.02 lbs
Gross Weight: 5.5kg/12.13 lbs
Plug: US Standard Voltage: 110V /
Plug: EU Standard Voltage: 220V
Notes
1.This table saw is a small table saw, and can only cut small parts, not an industrial table saw. Please see the parameters before you buy.
2.Please allow the slight color difference caused by the shooting light and the 1-3cm error due to manual measurement. Please make sure you do not mind before you order.
